Description
| SPECIFICATIONS | |
|---|---|
| Machine Model | 300 |
| Twisting | Applicable to over 7 wires, including silver-plated wire, tinned wire, enameled wire, insulated wire, bare copper wire, nickel wire, silver-plated copper wire, tin-plated copper wire, and cored wire.Suitable for super fine conductor and cored wire twisting. |
| Finished Wire Range | 19–32 AWG |
| Twisting Section | 0.0137–0.45 mm² |
| Diameter of Single Wire | Φ0.05–0.16 mm |
| Twisting Distance | 1.6–17.1 mm (24 twisting pitches) |
| Gross Weight | Maximum 30 kg |
| Maximum Rotation Speed | 3000 RPM (6000 turns/min) |
| Twisting Direction | Left or Right |
| Flat Cable | Polish rod traverse unit with adjustable pitch and throw. |
| Taking-Up Tension | Adjustable tension with no deformation of the pulled wire. |
| Auto-Stop Machine | Automatic braking in case of wire breakage inside or outside the machine.
Automatic meter counting with braking when the preset length is reached. |
| Machine Bearings | Main bearings made in Sweden; other bearings made in Japan. |
| Power | 5 HP controlled inverter |
