Description
| SPECIFICATIONS – Φ500 mm | |
|---|---|
| Machine Model | CBM-Φ500 |
| Finished Wire Range | 18–30 AWG |
| Twisting Section | 0.05–2.5 mm² |
| Diameter of Single Wire | Φ0.08–0.41 mm |
| Twisting Distance | 42–39.64 mm |
| Gross Weight | MAX 250 kg |
| Maximum Rotation Speed | 2500 RPM (5000 turns/min) |
| Twisting Direction | Left or Right |
| Flat Cable | Polish rod traverse unit with adjustable pitch and throw. |
| Taking-Up Tension | Adjustable tension with no deformation of the pulled wire. |
| Auto-Stop Machine |
Automatic braking in case of wire breakage inside or outside the machine. Automatic meter counting with braking when the preset length is reached, with warning signals before the machine stops. |
| Machine Bearings | Main bearings made in Sweden; other bearings made in Japan. |
| Power | 5–7.5 HP controlled inverter |
| Noise Level | Approx. 75 dB |
| Machine Dimension | L2690 × W1060 × H1230 mm |
| Net Weight | Approx. 2900 kg |
